Oil Tank Truck
13.1m³ Sinotruk Howo TX5 Fuel Tanker Truck
Full Safety Brake System, Euro Standard Tank for Refined Oil Delivery
This Howo TX5 fuel transport truck Model CL5181GJYZ6 features a 4700mm wheelbase and 13.1m³ tank volume. It is powered by MC07.25-60 engine with HW95508STC transmission, equipped with EBS+ESC, LDWS and FCWS radar safety systems.
The tank is made of 5mm thick Q235B steel for cylinder, head and partition with single compartment design. It comes with full European standard fittings, voice-alarm bottom valve and bidirectional oil pump; high-flow dispenser and 15m hose reel are optional.
Equipped with rear ladder, guardrails and toolbox, the truck complies with 2022 latest production standards. Complete registration documents and tank test reports are supplied, ideal for refined oil transportation.
Technical specifications
| Complete Vehicle Model | CL5181GJYZ6 |
| Tank Volume | 13.1 m³ |
| Wheelbase | 4700mm |
| Chassis Brand & Model | Howo TX5 special vehicle |
| Cab | TX-L cab |
| Rearview Mirror | Manual rearview mirror |
| Engine | MC07.25-60 |
| Transmission | HW95508STC gearbox + HW45ZC flange power take-off |
| Front Axle | VPD050QB disc front axle |
| Rear Axle | MCY11BES single disc rear axle |
| Fuel Tank | 200L |
| Axle Ratio | 4.63 |
| Frame | Single-layer frame (8/280) |
| Brake System | EBS + ESC |
