Garbage Truck

8CBM Self-Loading Compactor Garbage Truck, Sealed Waste Collection Vehicle

Isuzu Lingka National VI Medium Sanitation Truck | Auto Loading & Compaction, High-Efficiency Waste Transport for Town & Community
Model CL5100ZYS6BGX is an official certified 8CBM medium self-loading compactor waste truck built on Isuzu Lingka QL1100NBHACY sanitation chassis. Equipped with an 8 cubic meter high-strength manganese steel sealed bin and full-auto hydraulic bin lifting mechanism, it completes the whole workflow including waste feeding, high-pressure compaction, sealed storage and automatic unloading. Boasting high compaction ratio and large single load capacity, it greatly cuts transport trips. Fully enclosed bin plus independent sewage tank prevent sewage leakage and odor overflow to avoid secondary pollution. Adopted CAN bus intelligent control system with triple operation modes: cab panel, rear control box and wireless remote controller. Top-tier domestic hydraulic components ensure stable performance and low failure rate. Moderate body size brings outstanding trafficability, suitable for centralized domestic waste collection in urban roads, residential zones, industrial parks and towns. National VI emission standard allows registration nationwide, ideal bulk purchase model for municipal sanitation and property groups.
Technical specifications
Vehicle Model CL5100ZYS6BGX
Chassis Model QL1100NBHACY
Chassis Brand Isuzu Lingka
Drive Type 4×2 Single Axle 2WD
Engine Yunnei Dewei 160HP National VI Diesel Engine
GVW (Gross Vehicle Weight) 9975kg
Kerb Weight 6000-6500kg
Rated Payload 3280 / 3780kg
Overall Dimension 6750/7000×2250×2750mm
Bin Effective Volume 8m³
Compaction Ratio 1:0.75
