DongFeng Tianlong 30m³ Compressed Garbage Truck

Lightweight & Agile Design, Purpose‑Built for Waste Collection in Narrow Urban Streets

This compressed garbage truck is built on the Sinotruk Howo Zhuimeng series chassis (model ZZ1047C3313F145Z) with a 2800 mm wheelbase. Its compact dimensions of 5715×2000×2450 mm ensure excellent maneuverability in narrow alleys and congested urban districts. The refuse body is fabricated from high‑strength AG600XT steel, with 2.5 mm thickness for both side panels and floor, offering a robust yet lightweight structure. With a rated payload of 500 kg, curb weight of 3865 kg, and GVW of 4495 kg, the vehicle delivers cost‑effective operation and superior accessibility. The working device comprises a sealed bin and a hydraulic system for municipal solid waste collection and transfer. Side guards are made of Q235A carbon steel with bolted connections; the rear protection is integrated into the compactor unit, with a ground clearance of 430 mm. Multiple engine options are available, all meeting China VI emission standards and providing excellent fuel efficiency.
