Sewage Suction Truck
Dongfeng Kinland 15m³ High Pressure Washing & Sewage Suction Truck
National VI Single Axle Dual-Purpose Vehicle for Municipal Pipe Dredging & Septic Tank Sludge Cleaning
Dongfeng Kinland 15m³ washing & sewage suction truck integrates two core functions: high-pressure pipe dredging and vacuum sludge suction. The large 15 cubic meter tank minimizes back-and-forth transport trips, widely used for municipal sewer dredging, septic tank cleaning, construction mud pumping and urban flood drainage.
Equipped with Cummins 230HP National VI chassis, it delivers stable power and smooth driving. The sewage pump is driven by an independent auxiliary engine to avoid power loss during operation. The thickened carbon steel tank features excellent anti-corrosion and impact resistance; hydraulic tank lifting and full-open rear cover greatly simplify sludge discharge and tank cleaning. Standard long hydraulic hose reel and high-flow vacuum pump maximize working efficiency. The whole vehicle complies with official registration standards, and can be customized to meet overseas emission regulations, serving as the core workhorse for sanitation and dredging projects.
Technical specifications
| Model | CL5180GQW6CC |
| Chassis Model | DFH1180EX8 Dongfeng Kinland 4×2 Single Axle |
| Emission Standard | National VI (Euro 3/Euro 5 customizable for export) |
| Engine | Cummins ISB230 6.7L Diesel Engine, 230 HP |
| Gearbox | Fast 8-speed Manual Transmission |
| Wheelbase | 4700mm |
| Tire | 10.00R20 18PR Steel Wire Tire with spare tire |
| Brake System | Air Brake, ABS, Exhaust Brake |
| Total Tank Volume | 15m³ |
| Overall Dimension | 9150×2550×3550mm |
